The Roland VersaSTUDIO BF-16 is a compact yet powerful desktop UV flatbed printer designed for high-quality customization. With an A3 print area and support for objects up to 90 mm in height, it delivers sharp 1200 dpi output, multi-layer printing, and stunning gloss effects. Powered by advanced VersaWorks 7 RIP software and GREENGUARD Gold certified UV inks, the BF-16 lets you easily personalize phone cases, bottles, packaging, gifts, and more—combining professional performance with an affordable, space-saving design.
Print vibrant graphics and detailed text directly on objects up to 90 mm high.
Rapid and efficient production with high-speed printing capabilities.
Small footprint allows for convenient placement on your desktop.
Priced for start-up businesses with low budgets and high profit potential.
Produce vivid, high-definition prints with precision color accuracy.
Intuitive interface and user-friendly RIP software for simple operation.
| BF-16 | |||
|---|---|---|---|
| Printing Method | Piezo ink-jet method | ||
| Maximum objects to be printed on | Width | Max. 430 mm (16.9 in.) | |
| Length | Max. 340 mm (13.3 in.) | ||
| Thickness | Max. 90 mm (3.5 in.) | ||
| Weight | Max. 5 kg (11.0 lb.) | ||
| Maximum printing width/printing length | Max. 420 mm × 297 mm (16.5 in. × 11.6 in.) | ||
| Ink | Type | D-UAB (220 ml bottle) | |
| Colors | CMYK Wh Gl | ||
| Ink-curing unit | Built-in UV-LED lamp | ||
| Printing resolution (dots per inch) | Max. 1,200 dpi | ||
| Connectivity | Ethernet 1000BASE-T for control PC only | ||
| Rated input | 100 - 240 Va.c. 50/60 Hz 3 A | ||
| Power consumption | During operation | Approx. 250 W | |
| During standby | Approx. 60 W | ||
| Acoustic noise level | During operation | 67 dB (A) or less | |
| During standby | 50 dB (A) or less | ||
| Dimensions (Width x Depth x Height) | 964 mm × 908 mm × 592 mm (38.0 in. × 35.8 in. × 23.4 in.) |
||
| Weight | 90 kg (198.5 lb.) |
||
| Environment |
Temperature: 22° to 33°C (71.6°F to 91.4 °F), humidity: 30 to 65 %RH (no condensation) Even when the machine is not in use, keep it at a temperature of 22 to 33°C (71.6 to 91.4°F) and a relative humidity of 30 to 65% RH (with no condensation). |
||
| Included Items | Power cord, Cleaning liquid, Cleaning Swabs, User's Manual, USB Dongle for Future RIP, Software (VersaWorks), etc. | ||
