The VersaSTUDIO BD Series Desktop UV flatbed printer brings professional printing power to your desktop. Compact yet versatile, it lets you print directly on phone covers, gifts, bottles, and countless other items with vibrant, durable results. Perfect for small businesses, retail stores, classrooms, or creative studios, it makes product personalization quick, easy, and profitable.
With the VersaSTUDIO BD Series Desktop UV flatbed printer, you can easily print light colors on dark materials using white ink. The onboard Primer ink ensures strong adhesion on glass, metal, and other textured surfaces, delivering bold and vibrant results for fashion items, tech accessories, branded products, and more.
Unlocks high-margin customization for a wide range of profitable products.
Delivers sharp, vibrant results that meet professional standards and impress customers.
Gives new entrepreneurs everything they need to start printing and profiting immediately.
| BD-8 | BD-12 | ||
|---|---|---|---|
| Printing Method | Piezo ink-jet method | ||
| Attachable objects to be printed on | Width | Max. 9.4 in (240 mm) | Max. 13.1 in (335 mm) |
| Length | Max. 7 in (178 mm) | Max. 9.4 in (240 mm) | |
| Thickness | Max. 4 in (102 mm) | ||
| Weight | Max. 6.6 lb (3 kg) | Max. 11 lb (5 kg) | |
| Maximum printing width / length | Max. 8.2 in × 5.8 in (210 mm × 148 mm) | Max. 12 in × 8.2 in (305 mm × 210 mm) | |
| Ink | Type | ECO-UV (EUV5) 220 ml cartridge | |
| Colors | Five colors (cyan, magenta, yellow, black, and white) and primer or gloss | ||
| Ink-curing unit | Built-in UV-LED lamp | ||
| Printing resolution (dots per inch) | Max. 1,440 dpi | ||
| Connectivity | Ethernet (100BASE-TX/1000BASE-T, automatic switching) | ||
| Power-saving function | Automatic sleep feature | ||
| Rated input | 100-240 Va.c. 50 / 60 Hz 1.1A | 100-240 Va.c. 50 / 60 Hz 1.2A | |
| Power consumption | During operation | Approx. 90 W | Approx. 100 W |
| Sleep mode | Approx. 30 W | Approx. 40 W | |
| Acoustic noise level | During operation | 59 dB (A) or less | 60 dB (A) or less |
| During standby | 52 dB (A) or less | 55 dB (A) or less | |
| Dimensions (Width x Depth x Height) | 30.3 in × 23.1 in × 22.9 in (768 mm × 586 mm × 580 mm) | 39.2 in × 28 in × 23 in (995 mm × 710 mm × 583 mm) | |
| Weight | 134.5 lb (61 kg) | 177 lb (80 kg) | |
| Environment | During operation *1 | Temperature: 68°F to 89.6°F (20°C to 32°C) (71.6°F [22°C] or higher recommended) Humidity: 35%RH to 80%RH (no condensation) |
|
| Not operating | Temperature: 41°F to 104°F (5°C to 40°C) Humidity: 20%RH to 80%RH (no condensation) |
||
| Included Items | Power cord, Cleaning liquid, User's Manual, Software (FlexiDESIGNER VersaSTUDIO Edition, VersaWorks, Roland DG Connect), etc. | ||
